Reel Stands For Rent

Made from top-quality, structural-grade steel tubing, our reel stands are rugged and durable, with load capacities from 20,000. lbs to 26,000 lbs. You can rent reel stands from Custom Truck by the week or by the month, at very economical rates and with full support from our team of technicians.



Reel stands for rent with quick-disconnect fittings

Features such as quick-disconnect fittings make our reel stands ideal for busy utility companies in need of equipment that is both reliable and simple to use. Request a quote now and feel free to contact us at 833-305-RENT (7368) if you’d like to rent reel stands from any of our locations in North America.

806-3290

8,000 lbs 84 in Diameter x 54 in Width Manual Brake Stationary Reel Stand
Equipment Cat-Class 806-3290
$795
  • Reel max 84 in. by 54 in. weighing up to 8,000 lbs.
  • 16 in. bronze brake with manual caliper
  • 2.5 in. arbor bar with lock cone collars

806-3300

16,000 lbs 96 in Diameter x 66 in Width Hydraulic Brake Stationary Reel Stand
Equipment Cat-Class 806-3300
$987
  • Reel max 96 in. by 66 in. weighing up to 16,000 lbs.
  • 16 in. stainless steel tension brake
  • 3 in. arbor bar
  • Forklift tubes

806-3400

20,000 lbs 108 in Diameter x 67 in Width Hydraulic Brake Stationary Reel Stand
Equipment Cat-Class 806-3400
$1,097
  • Reel Stand
  • Reel max 108 in. by 67 in. weighing up to 20,000 lbs.
  • Hydraulically applied brake caliper actuated by hand pump
  • 5 in. arbor bar

806-3415

20,000 lbs 108 in Diameter x 80 in Width Manual Brake Stationary Reel Stand
Equipment Cat-Class 806-3415
$1,500
  • Stationary single reel stand frame
  • Frame made of high-strength steel tubing
  • Manual 20 in. diameter aluminum brake disc
  • Reels with an OD of up to 108 in and a width of 80 in.
  • A 20,000 lb reel capacity with a 3-15/16 in. diameter bar.

806-3600

20,000 lbs 108 in Diameter x 83 in Width Manual Brake Stationary Reel Stand
Equipment Cat-Class 806-3600
$1,890
  • Reel max 108 in. by 83 in. weighing up to 20,000 lbs.
  • Power wind reels with either a hydraulic tool circuit or tensioner
  • Offers a manual tension brake to tension a reel

806-3410

24,000 lbs 96 in Diameter x 67 in Width Manual Brake Stationary Reel Stand
Equipment Cat-Class 806-3410
$1,443
  • Reel max 96 in. by 67 in. weighing up to 24,000 lbs.
  • Integrated manual controls
  • Quick-disconnect fittings
  • Manual, mechanical payout brake.

806-3500

26,000 lbs 102 in Diameter x 70 in Width Hydraulic Brake Stationary Reel Stand
Equipment Cat-Class 806-3500
$2,100
  • Reel max 102 in. by 70 in. weighing up to 26,000 lbs.
  • Hydraulically controlled with negative brake
  • 4 in. arbor bar standard with nylon bushings to accommodae 5.25 in. reels
  • Available 3 in. arbor bar
  • H-frame attachment available separately

806-3525

30,000 lbs 120 in Diameter x 85 in Width Hydraulic Brake Stationary Reel Stand
Equipment Cat-Class 806-3525
$1,740
  • Reel max 120 in. by 85 in. weighing up to 30,000 lbs.
  • 20 in. Aluminum/Bronze disc brake
  • Hydraulic applied caliper braking system
  • Hand pump with gauge and accumulator system
  • Safelock Reel Securing System

806-3550

30,000 lbs 120 in Diameter x 85 in Width Hydraulic Brake Stationary Reel Stand
Equipment Cat-Class 806-3550
$1,800
  • Condux reel max 120 in. by 85 in weighing up tp 30,000 lbs
  • S+R reel max 108 in. by 83 in weighing up tp 30,000 lbs
  • Hydraulically power wind and brake
  • Condux RS30 has a 4 in. arbor bar and the S+R includes a 5 in. arbor bar.

806-3650

30,000 lbs 120 in Diameter x 85 in Width Manual Brake Stationary Reel Stand
Equipment Cat-Class 806-3650
$1,448
  • Reel max 120 in. by 85 in. weighing up to 30,000 lbs.
  • Hydraulically controlled with manual brake
  • 4 in. arbor bar standard with nylon bushings to accommodae 5.25 in. reels
