806-0120

1,100 lbs Underground Puller
Equipment Cat-Class 806-0120
$2,910
  • Condux trailer-mounted fiber optic puller
  • Installs underground telecom cables
  • Electronic Control System
  • Digital Chart Recorder and Set Tension Limits
  • Controlled force for pulling rope or tape

806-2730

10,000 lbs Underground Puller
Equipment Cat-Class 806-2730
$9,445
  • 10,000 lb. pulling capacity
  • 2,200 ft. of 7/16 in. steel wire rope
  • 2-speed gearbox
  • Twin 7 in. capstans
  • Wireless remote and digital pull/speed recorder
  • NO Air Compressor

806-2740

10,000 lbs Underground Puller Air Compressor
Equipment Cat-Class 806-2740
$6,790
  • 10,000 lb. pulling capacity
  • 2,200 ft. of 7/16 in. steel wire rope
  • 2-speed gearbox Twin 7 in. capstans
  • Wireless remote and digital pull/speed recorder
  • Air Compressor

806-2745

11,000 lbs Underground Puller
Equipment Cat-Class 806-2745
$8,682
  • 11,240 lb. pulling capacity
  • 2,500 ft. of 1/2 in. steel wire rope
  • Double capstan system
  • Remote and digital pull/speed recorder
  • NO Air Compressor

806-2750

15,000 lbs Underground Puller
Equipment Cat-Class 806-2750
$12,093
  • 15,000 lb. pulling capacity
  • NO Air Compressor

806-2800

20,000 lbs Underground Puller
Equipment Cat-Class 806-2800
$6,686
  • Puller known as 'The Hydra Hog'
  • Equipped with a horsepower efficient hydrostatic drive
  • Creates over 24,000 lb. line pull
  • Closed loop system offers full pulling pressure to the two-speed final drive motor, providing slow inching capability

806-2770

22,000 lbs Underground Puller
Equipment Cat-Class 806-2770
$9,841
  • 22,500 lb. pulling capacity
  • 3,280 ft. of 5/8 in. steel wire rope
  • Double capstan system
  • Wireless remote and digital pull/speed recorder
  • NO Air Compressor

806-2900

40,000 lbs Underground Puller
Equipment Cat-Class 806-2900
$8,013
  • Hydrostatic puller
  • Diesel, 4 cylinder, water-cooled engine
  • “Feather touch” electro-hydraulic proportional controls
  • Overhead wire speeds of zero feet per minute to in excess of six miles per hour
  • Underground pulls from 0 to 40,000 lb.
  • One man operation set-up

806-0725

40,500 lbs Overhead Puller
Equipment Cat-Class 806-0725
$24,277
  • 40,500 lbs. of pulling capacity
  • String one rope up to 1 3/32 in. (28 mm) in diameter
  • Features bull-wheel grooves made from heat treated steel
  • Wireless remote and digital pull/speed recorder

806-2790

40,500 lbs Underground Puller
Equipment Cat-Class 806-2790
$15,000
  • 40,500 lbs. of pulling capacity
  • String one rope up to 1 3/32 in. (28 mm) in diameter
  • Features bull-wheel grooves made from heat treated steel
  • Wireless remote and digital pull/speed recorder

806-2700

5,000 lbs Underground Puller
Equipment Cat-Class 806-2700
$8,370
  • 5,000 lb. pulling capacity
  • 1,500 ft. of 3/8 in. steel rope
  • Equipped with a tension dynamometer and adjustable overload cut-off
  • Ideal for telecommunication cables

806-2705

7,500 lbs Underground Puller
Equipment Cat-Class 806-2705
$10,050
  • Electric Underground Puller
  • 7,500 lb. pulling capacity
  • All-electric drivetrain
  • 2,000 ft. of 3/8 in. steel wire rope
  • 3-speed gearbox
  • Fully articulating, 3-axis boom
  • Wireless remote and digital pull/speed recorder
  • NO air compressor

806-2710

7,500 lbs Underground Puller
Equipment Cat-Class 806-2710
$5,792
  • 7,500 lb. pulling capacity
  • 2,000 ft. of 3/8 in. steel wire rope
  • 3-speed gearbox
  • Twin 6 in. capstans
  • Wireless remote and digital pull/speed recorder
  • NO air compressor

806-2715

7,500 lbs Underground Puller Air Compressor
Equipment Cat-Class 806-2715
$8,476
  • Pulling capability of 7,500 lbs. or 10,000 lbs.
  • BOSS Air System’s air compressor
  • Self-supported, 3-axis boom
  • Hydraulically driven twin capstan bullwheels
  • 3-speed gearbox

806-2725

8,500 lbs Underground Puller
Equipment Cat-Class 806-2725
$7,600
  • 8,500 lb. pulling capacity
  • 3,000 ft. of 3/8 in. steel rope
  • Hydraulically controlled boom and outriggers
  • Wireless remote and digital pull/speed recorder
  • NO Air Compressor

806-2720

8,500 lbs Underground Puller Air Compressor
Equipment Cat-Class 806-2720
$8,476
  • 8,500 lb. pulling capacity
  • 3,000 ft. of 3/8 in. steel rope (Blue Ox)
  • 2,300 ft. of 7/16 in. steel rope (TSE)
  • Hydraulically controlled boom and outriggers (Blue Ox)
  • Wireless remote and digital pull/speed recorder (Blue Ox)
  • Air Compressor
